Product Description:
Hi-rigidity machine structure designs and the main casting is made of meehanite cast iron which is annealed perfectly to eliminate internal residual stress. YˇBZ axis square rigid ways and dovetail slidway for saddle ˇ] X axis ˇ^ , furthermore, the all slideway be treated heat-treatment & precisely ground & scrapped etc. Rugged stand & boxed structure column and integral heavy duty bed type designs and coupled reinforced ribs, advance machining servicing life & accuracy. The spindle is made of SCM-21 steel and tempered stress relieved, carburized & precisely ground etc., and then, equipp
Double nut-precision ball screw for XˇBY and Z-axis. It keeps high precision and durability life of machine.
XˇBYˇBZ axis employ DC servo motors. Providing variable feed speed change. Rapid feed rate provides 2-3 times higher efficiencu than frequency inverter controlled motor. Greater torque output at low speed running. Can be fitted with optional MPG hand wheel. ˇ] opt. ˇ^
The automatic lubrication system with adjustable the timing and flow to provide the excellent lubricating oil onto all the sliding ways. When lubricant reaches control-limited, it is ringing an
