Product Description:
AF-15AˇE33 International standard design: VCT cable, auto-cut, silicon carbide mechanical seal, high grade cast iron, good quality and performance. Multiple impellers design, there are three kinds of impeller to handle different sewage and waste water. Full range from low head to high head, compact and easy installation, equipped with guide rail system available.
Diameter(mm) 150~400 Pumping liquid Liquid temp 0~40oC Liquid nature Aquaculture water industrial water and sewage Max depth 30m Pump Structure Impeller Enclosed channel non-clogging impeller Mech seal Double mechanical seal Protector WD water derector(Optional) Material Upper cover FC-200 Bearing Heavy duty bearing Impeller FC-200 Casing FC-200 Wear ring Bronze Casing cover FC-200 M.seal Silicon carbide Motor Type Dry motor Insulation Polarity F ClassˇE4P/6P Frequency 50Hz/60Hz Protector Miniature termal protector(MTP) Material Frame FC-200
The 100% quality control procedure for motor precisionˇAmanufactured with whole new laminated sheet steelˇCshaft and rotor was manufactured with heat treatmentˇAprecisionˇCStable motor characteristics with high efficiencyˇC Professional production assembly lineˇAconduct with synthesized production testˇCEnsure the pump qualityˇC Standard accessoriesˇGVCT cableˇAEPOXY resin seal water resistant cable baseˇAefficient dry type motorˇAAC motor protectorˇAdule machanical sealˇCIt is economical and worthyˇC Non-clogging impeller designˇAdealing with waset water sewage with best dewatering efficienc
Product Description:
Equipped with auto-cut, silicon carbide double mechanical seal, epoxy cable base treatment. Robust cast iron construction and compact design. Available with TOS guide rail system. Wide applications of its design in higher efficiency and high head impeller
Product Description:
Suitable for handling light chemical liquid, for example,sewer`s sewage, various industries` waste water, food industry waste water, salty water, and sea water. This type of pumps functions excellently.
Product Description:
HLC Sewage Pump Purposes: industry mass water supply, farming irrigation, community water supply, factory water supply, fishery cultivation, building sewage disposal, integrated sewage disposal, chemical engineering water supply Horsepower: 1/2HP ~ 10HP Lift: 5m ~ 20m Standard water volume: 0.16m3/min ~ 8m3/min Caliber: 1 1/2" ~ 12"
Product Description:
MODEL ADVS series OUTPUT 1~5 HP , 0.75~3.7 KW OUTLET 50 ~ 80 mm , 2"~3" RATED H 11.2~10.4 (M), Q 200~820 (l/m) MAXIMUM H 13.5~21 (M), Q 35~140 (l/m) DIMENSION 250~280L X 172~233W X 400~723H(mm) WEIGHT 19 ~- 60 KGS
