Product Description:
The model is especially for small and medium production of elastic and common tapes. The machine is single cylinder with horizontal-movement unit. The tapes spirally wind around the cylinder. The upper roller on the cylinder will do one-side adjustment according to the amount of the contraction to be not horizontal and achieves the best outcome. The rubber squeeze rollers for starching is by pneumatic operation.
Machine Specification: Capacity : 0~400M/Min. Output : MAX 2 PCS Machine Power : 4 HP
Product Description:
The model is for tapes starching and ironing, and is equipped with the best temperature-control, tape-outlet unit and automatic tension-control unit, ensuring tapes neat, tidy and smooth . The machine heating is available in gas, electric, thermosol oil or steam. Clients could choose the most economical heating way to reduce costs. This model is especially suitable for small but diversified production.
Machine Specification: Capacity : 30M/Min./PC Output : 2 PCS Machine Power : 5 HP
Product Description:
This model is under electronic control with tension auto-adjusting unit to balance and smooth the tapes. From tape inlet steaming coating pre-dry finishing winding , the whole process is under continuous and consecutive production, saving labor cost from this high - efficient automatic finishing machine.
Machine Specification: Capacity : 35 M/Min./PC Output : 1PC Machine Power : 25 HP
Product Description:
1.patent design overflow and jetflow,twin use nozzle.can choose all kinds of water flow dlrection to sult different klnds of fabrics¡O replace the traditionaltype of pure overflow or pure jetflow machines. one machine muiltiple use double your return on the investment¡O
2.complex flow tube:first portion is in circular shape+second portlon is in rectangular shape flowing tube¡O when the fabric go into the flowtube,the followlng functlon will happen: (1)warp crease mark eliminate function¡A& relex effect in circular tube¡O (2)open weft curly edg
Product Description:
EASY OPERATION Compact and human-engineering construction enable the easy operation on ground without operating platform or any aid of pit.
HEAT EXCHANGER This high efficency multi-tube heat exchanger has such a heating/cooling capacity that can increase the temperature from 20¢J to 140¢J in 30 minutes, or decrease the temperature from 140¢J to 80¢J in 20 minutes by applying 4 steam or 1 kg/cm2 cooling water
Product Description:
1.special series connection type twln nozzle. one in front and the other at rear. help to push and transport fabric. help to lncrease the number of times saturate and in contact with the fabrics. increase dye quality¡O
2.use large water flow, soft type overflow¡O total nozzle pressure is only o.2-o.5kg/cm. the hitting force to the fabrlc is lower to the minimum to avoid the problem of pilling and split cracks of fabrlcs¡O
3.the delivery tube is design to go downward then turn upward.this will create the push effects to change the position of fabrlc al
Product Description:
Each tube has two nozzle, first one in front and second one at rear. Enable the smooth delivery of fabric and no congestion inside the delivery tube. AK-TO allows even separation of large water flow by the main pump. Allows very low nozzle pressure and achieve no pilling, no twist or breakage of yarn and maintain the elasticity of the spandex type fabric. The best option for high quality fabric process.
Product Description:
TWIN ACCELERATOR SYSTEM The special construction of nozzle with twin dimension assembled is flexible for the processing of various kinds of knitted and woven fabrics¡DHigh circulating rate of dyeing liquor assure even tempefature distributed over the whole dyeing tank. Adjustable stepless speed of driving reel will not only forward the fabrics smoothly¡Abutalso achieve optimum process effect.The skill requirement of operator is not necessary definitely¡D
