Product Description:
Model KKA-430 KKA-530 KKA-440 KKA-540 KKA-550 Moulding size (LxHxW) 450x300x250 mm 500x300x250 mm 450x400x250 mm 500x400x250 mm 550x400x300 mm Shell moulding size (LxHxW) 370x280x200 mm 420x280x200 mm 370x380x200 mm 420x380x200 mm 470x380x250 mm Operating style Individual operating-single auto cycle operating-progressive auto operating Forming capacity 20-90seconds/cycle Heating style By LPG or electric heating Max. blowing volume 20kg 25kg 25kg 25kg 30kg Sand storage volume 250kg 300kg 300kg 300kg 450kg Operating pressure 5-6kg/cm2 Sand blowing pressure 1-4kg/c
Product Description:
Model KKE-430 KKE-530 KKE-440 KKE-540 KKE-550 Moulding size (LxHxW) 450x300x150 mm 500x300x200 mm 450x400x250 mm 500x400x300 mm 550x400x350 mm Shell moulding size (LxHxW) 370x280x100 mm 420x280x150 mm 370x380x200 mm 420x380x250 mm 470x380x300 mm Operating style Individual operating-single auto cycle operating-progressive auto operating Forming capacity 20-90seconds/cycle Heating style By LPG or electric heating Max. blowing volume 10kg 15kg 20kg 25kg 25kg Sand storage volume 250kg 300kg 300kg 300kg 450kg Operating pressure 5-6kg/cm2 Sand blowing pressure 1-4kg/cm
Product Description:
This m/c is employed heating core moulding & compressed air to blow small shell moulding & core, Simple of operating, low purchasing cost and well suited mass production of small shell moulding & core.
