Product Description:
1. SPECIAL DESING FOR DRIVING. 2. SPECIAL DESING VIBEATORY SPRING BY 15 IS MOST SUITABLE FEEDING. 3. SUITABLE FOR HEAVY BY HIGH SPEEDING.
Product Description:
Hydrondyamic Effect If the spindle speed is zero, the hydrodynamic support is zero and the bar rests on the feed tube. The revolving bar products increased oil pressure ang the bar is lifted from the bottom of the feed tube. With increasing speed, the hydrodynamic force increases and the bar revoves centrally ensuring a smooth feed.
Product Description:
High Loading Speed, Specially Developed Design
No special requirements or restrictions on material straightness. Material rotates within machining area and spindle length of lathe. Lathe spindle speed can be maximized. Material can be round, hexagonal and shaped. Material length can be uniform or random. Easy yo operate and maintain Small footprint Different speed control on feeding and retracting. Variable feeding torque applies on different diameter (weight) and length to avoid bending of material. Sub-spindle mode.
Product Description:
This barfeeder is suitable for small and precision spare parts such as watches, electronic components, etc. Hydraulic-type, high loading, ensuring rotational speed up to 20,000 rpm. Employs MITSUBISHI AC servomotor to transmit. Adopts PLC control circuit which features excellent stability and easy to operate. Various parameter settings, alarm detection and function display.
Product Description:
Hydraulic type, high loading and ensures silent turning. Various parameter settings, alarm detection and function display. Employs Mitsubishi AC servomotor to transmit. Adopts PLC control circuit featuring excellent stability and easy operation. High-density steel structure ensuring rigidity and durability. Electronic controller synchronized tracing device, Quick-change guide channel, easy and convenient to change.
