Features
FANUC or Mitsubishi control system
Handheld MPG manual position unit
X and Z axis are assembled with precision ball screws and 60 degree taper precision bearings to achieve minimal backlash.
Standard spindle bore 153mm (6"). 9", 10", 12", 14", 16", 21" s pindle bores optional.
8 position electrical disc turret (opt.)
4 position horizontal horizontal turret (opt.)
Hydraulic/air chuck and cylinder or customize face plates (opt.)
Double turret configuration (opt.)
Automatic four step variable speed changing will ensure full torque output even at low spindle rpm
Precision spindle supported by 3 point Timken bearings
Integrated full splash guard housing to ensure operator safety and clean environment
Electrical cabinet is equipped with heat exchanger, which protects the electronics from industrial air/oil/water pollutants, reduces cabinet temperature, and safe guards the integrity of the electronic components.
Spindle cooling system can reduce the temperature of the spindle to minimize the thermal expansion (std.)
All gears are made of Cr-M steel and are precision hardened and ground to ensure low noise and long life.
Double chuck configuration (opt.)
Laser verified spindle alignment, X, and Z position accuracy
C axis and power turret |
|
|
|
|
| |
|
|
| |
| |
 |
|
