Chin Fu Industrial Co., Ltd. |
|
|
|
|
|
|
|
|
SPECIFICATION CYM-031A CYM-031B DIAMETER OF ORIGINAL WOOD 70~600mm 70~600mm LENGTH OF ORIGINAL WOOD 127~520mm 127~762mm THICKNESS OF PEELING 0.35~5mm 0.35~3mm R.P.M. 40 OR 54 40 OR 54 HORSEPOWER 1/2HP + 7 1/2 HP 1/2HP + 10HP N.W. 1080 KGS 1170 KGS G.W. 1140KGS 1330KGS MACHINE SIZE (LxWxH) 99"x40"x40" 110"x40"x45" PACKING SIZE (LxWxH) 102"x43"x50" 115"x43"x51" |
|
|
|
|
|
|
|
|
|
|
|
