COMPUTER CONTROL:
200 programs can be stored in the memory providing 3200 steps. it gives you programming flexibility. Data setting and modification is very easy, no need of assistance of a computer expert. The sequence trouble may be identified from the signals on control panel
CREEP FEED RIP CUTTING:
Permit operator make random or identical widths of cut.
MOTORIZED POWER FENCE:
Auto rip cutting is performed with the powered rip fence. Fence movement is driven by rack and pinion mechanism and is guided with high precision slide rail guarantees extremely parallel to cutting line.
SAW CARRIAGE STROKE
CONTROL:
Enable a selection of full stroke or stroke limitation as varied with panel measurement.
AC SERVO MECHANISM:
The mechanism drives AC motor, combined with rotary encoder feedback offers the maximum positioning accuracy to 0.02mm. It's convenient for motor replacement and reduce trouble to minimum.
VARIABLE FEED SPEED:
Variable adjustment of saw feeds to suite for various types of panel, and get maximum efficiency at all times. Saw feed speeds range 15~25 meters per minute. Fast return speeds 30~50 meters per minute. |
|
|
|
|
| |
|
|
| |
| |
 |
|
