SD CNC FUNCTIONS 12.1" TFT LCD display panel. PC based controller for cnc drilling edm. Use friendly and compatible. Auto electrode compensation when machining a hole, the electrode is over. 4 axes close loop control. Automatic tiil changer & intelligient tool compensation Auto tool changer. (OPT) Auto compensating of exchanged new electrode during machining, Electrode is finished. When the preset depth is reached, electrode automatic detecting and be risen to workpiece surface. Variable depth control of machining. Simulation and working path display. 100 condition files, each file store 100 sets of datas. 100 sets of drilling depth. Fiexible & maintainable System self diagnosis display. Hardware status display. Alarm history management. PLC ladder on line monitoring RS232 transfar function. Chinese / English conversion. Dialogue programming G/M code programming. Background editing. Special modular maching rectangle pattern). Auto edging, center of two points, center of circle including electrode radius compensation. |
|
|
|
|
|
|
|
|
|
|
|
